Horizontal Packing Machine with Down Film

Features：

1. Double motor, double Panasonic transducer control and PLC controller, flexible bag length cutting, operator needn't to adjust the unloading working, saving time and films. 2. Buttoned human-machine screen, Chinese or English displaying, convenient and quick parameter setting.

3. Self diagnosis failure function, clear failure display.

4. High sensitivity optical electric color mark tracking, digital input cut position which makes the sealing and cutting more accurate. 5. Separate PID control to temperature, suitable for various packing materials. 6. Stopping the machine in selected position, no sticking to the knife and no waste packing film.

7. Simple driving system, reliable working, convenient maintenance.

8. All the controls are achieved by software, convenient for function adjusting and upgrading.

Application:

Suit for food, medicine, daily necessities, disposable product, hardware product, plastic product, toy, industrial goods, industrial parts and car accessories industries.

Product Details

Specification:

Model	HP-250X	HP-350X
Film Width	Max. 250mm	Max. 350mm
Bag Length	60-190mm or 120-280mm	60-190mm or 120-280mm
Bag Width	30-110mm	50-160mm
Product Height	Max. 55mm	Max. 55mm
Film Roll Diameter	Max. 320mm	Max. 320mm
Machine Weight	500kg	600kg
Machine Size(LWH)	3770×670×1450mm	4020×745×1450mm
Packing Speed	40-230 bag/min	40-230 bag/min
Power Supply	220V 50/60Hz 2.4KW	220V 50/60Hz 2.6KW

Model	HP-450X	HP-600X
Film Width	Max. 450mm	Max. 600mm
Bag Length	130-450mm	120-450mm
Bag Width	50-180mm	50-200mm
Product Height	Max. 75mm	Max. 75mm
Film Roll Diameter	Max. 320mm	Max. 320mm
Machine Weight	700kg	750kg
Machine Size(LWH)	4020×800×1450mm	4380×970×1500mm
Packing Speed	30-150 bag/min	20-80 bag/min
Power Supply	220V 50/60Hz 2.8KW	220V 50/60Hz 3.6KW
